Features

Output Current up to 0.5A

Output Voltages of 5,6,8,9,12,15,18,24V

Thermal Overload Protection Short Circuit Protection

Output Transistor Safe Operating area (SOA)Protection

Description

The 78MXX three-terminal positive regulators are available

in the TO-252 package with several fixed output voltages

making it useful in a wide range of applications.

Internal Block Digram

Absolute Maximum Ratings

Parameter Symbol Value Unit

Input Voltage (for VO= 5V to 18V)

(for VO= 24V) VIN35

40 V

Thermal Resistance Junction-Case RθJC2.5 °C/W

Thermal Resistance Junction-Air

(Ta = +25°C) RθJA92 °C/W

Operating Junction Temperature Range TOPR0～150 °C

Storage Temperature Range TSTG
